| Nominal Capacity | 1500mAh |
| Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃2℃ |
| Nominal Voltage | 3.0 V |
| Maximum Continuous Current | 1500mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 3000mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -40℃ to +85℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 20.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Battery Characteristic
The rated voltage of each battery is 3.0V
We provide the specific energy density up to 225Wh/kg
- Wide Operating Temperature Range
We provide a wide operating temperature range, from -40℃ to +85℃
Under the condition of normal temperature, the battery self -discharge rate of no more than 2% per year
High capacity, stable performance, stable discharge voltage, and no voltage passivation after long time storage
Battery sealing using the fully sealed structure to reduce the leakage of the battery, make the battery can be stored at room temperature for more than 10 years
The battery safety performance is good, high reliability, and pollution-free, environmental friendly.
2. Main Applications
Life jacket, signal light, buoy, etc.
Well pressure meters in high temperature, float meter, logging while drilling (LWD), measure while drilling (MWD), etc.
RFID products, road toll transponder, IC cards, etc.
3. Manufacturing Advantages
- There is advanced automatic technology in HCB;
- Cathode is produced by the unique advanced manufacturing process;
- Varity of solutions including high power, high capacity (hermetic & semi sealing), low temperature etc;
- It is workable for us to provide multiple cascade and parallel connecting ways and combining suggestions with HCB customers;
- HCB is the first one who uses the industrial hermetic sealing cell.
