| Nominal Capacity | 1500mAh |
| Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃ |
| Nominal Voltage | 6.0 V |
| Maximum Continuous Current | 1500mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 3000mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -40℃ to +85℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 45.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Battery Characteristic
The rated voltage of each battery is 6.0V
The specific energy density of each battery is 200Wh/kg
- Wide Operating Temperature Range
We provide a wide operating temperature range, from -40℃ to +85℃
The battery self-discharge less than 2% per year at room temperature
High capacity, stable performance, without passivation
Hermetic welding sealing to reduce the leakage for extending the shelf life to more than 10 years
High safety performance, reliable and environmental friendly
2. Main Applications
Automatic meters (water meter, electric meter, gas meter), conventional meters, etc.
Well pressure meters in high temperature, float meter, logging while drilling (LWD), measure while drilling (MWD), etc.
Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.
